You’ve bought the TV, you’ve got the mount, and you’re ready to install. But then you dump out that bag of hardware and face an overwhelming question: Which fasteners do I actually use?
The answer depends on what your wall is made of and where you’re mounting. Using the wrong hardware is one of the most common—and dangerous—TV mounting mistakes. The right choice is the difference between a TV that stays on the wall for years and one that crashes to the floor.
This guide breaks down the two main TV mounting fasteners—toggle bolts and lag bolts—explaining when to use each, how to choose the right size, and what to do for different wall types.
The Two Main TV Mounting Fasteners
Lag Bolts (Lag Screws)
What they are: Heavy-duty screws with coarse threads designed to grip into wood
How they work: The thick, aggressive threads bite into wood fibers, creating strong holding power through mechanical grip
Best for: Wood studs, solid wood, some engineered wood products
Not for: Drywall alone, metal studs, concrete, brick
Toggle Bolts
What they are: Bolts with expandable wings or channels that grip behind the wall surface
How they work: A mechanism (wings, straps, or channels) passes through a hole in the wall and expands or seats against the backside, creating an anchor point
Best for: Drywall without studs, metal studs, hollow walls, hollow core concrete block
Not for: Solid wood (use lag bolts), solid concrete (use concrete anchors)
When to Use Lag Bolts
Ideal Scenarios for Lag Bolts
Mounting directly into wood studs:
- Standard residential drywall over wood framing
- Plaster over wood studs
- Solid wood posts or beams
Why lag bolts are preferred for studs:
- Maximum holding power (200-500+ lbs per bolt)
- Simple installation
- Most secure connection possible
- Direct structural attachment
Lag Bolt Specifications
| Bolt Size | Diameter | Holding Power (per bolt in stud) | Best For |
|---|---|---|---|
| 1/4” x 2.5” | 0.25” | 200+ lbs | Light to medium TVs |
| 1/4” x 3” | 0.25” | 250+ lbs | Standard installations |
| 5/16” x 3” | 0.3125” | 350+ lbs | Heavier TVs |
| 3/8” x 3.5” | 0.375” | 500+ lbs | Heavy-duty installations |
How to Use Lag Bolts Correctly
Step 1: Locate the stud
- Use stud finder (electronic or magnetic)
- Verify with thin nail test
Step 2: Mark and drill pilot hole
- Pilot hole diameter: slightly smaller than bolt core (not thread) diameter
- For 1/4” lag: use 3/16” pilot hole
- For 5/16” lag: use 7/32” pilot hole
- Drill depth: bolt length minus wall thickness
Step 3: Drive the lag bolt
- Use socket wrench or impact driver
- Drive until washer is snug against bracket
- Don’t overtighten (can strip hole or split stud)
Common lag bolt mistakes:
- ❌ No pilot hole (splits wood, reduces strength)
- ❌ Pilot hole too large (threads don’t grip)
- ❌ Pilot hole too shallow (bolt doesn’t seat)
- ❌ Overtightening (strips threads from wood)
When to Use Toggle Bolts
Ideal Scenarios for Toggle Bolts
Mounting without studs available:
- Drywall-only attachment points (when studs don’t align)
- Steel stud walls (high-rise condos, commercial buildings)
- Hollow-core block walls
Why toggles are needed:
- Lag bolts have nothing to grip in hollow walls
- Standard screws pull out of drywall easily
- Toggles create anchor point behind the wall surface
Types of Toggle Bolts
1. SnapToggles (Strap Toggles)
How they work:
- Metal channel passes through hole
- Pull straps seat channel against back of wall
- Snap off excess straps
- Bolt threads into channel
Advantages:
- Highest holding power (300+ lbs per toggle)
- Channel reusable—can remove and reinsert bolt
- Works in metal studs and drywall
- Consistent, reliable installation
Best for: TV mounting on metal studs or drywall
2. Spring Toggle Wings
How they work:
- Folded wings pass through hole
- Wings spring open behind wall
- Tightening bolt draws wings against back surface
Advantages:
- Less expensive than SnapToggles
- Available everywhere
- Works in various wall types
Disadvantages:
- If bolt removed, wings fall inside wall
- Require larger holes than SnapToggles
- Can spin inside wall during installation
3. Molly Bolts (Hollow Wall Anchors)
How they work:
- Sleeve expands behind wall as screw tightens
- Creates anchor point in hollow walls
Advantages:
- Good for lighter loads
- Common and inexpensive
Disadvantages:
- Lower weight capacity than toggles
- Requires precise hole sizing
- Can strip if overtightened
Toggle Bolt Specifications
| Type | Bolt Size | Holding Power (in 1/2” drywall) | Hole Size |
|---|---|---|---|
| SnapToggle | 1/4” | 265 lbs | 1/2” |
| SnapToggle | 3/16” | 170 lbs | 3/8” |
| Spring Toggle | 1/4” | 100 lbs | 5/8” |
| Spring Toggle | 3/8” | 170 lbs | 7/8” |
| Molly Bolt | 3/16” | 50 lbs | 1/4” |
Note: Actual capacity depends on wall condition. These are ideal ratings.
How to Use Toggle Bolts Correctly
For SnapToggles:
- Drill appropriately sized hole (check package)
- Insert metal channel through hole
- Pull straps until channel seats against back of wall
- Holding tension, slide plastic cap to wall surface
- Snap off protruding straps
- Insert bolt through bracket into channel
- Tighten until secure
For Spring Toggles:
- Drill appropriately sized hole
- Thread toggle wings onto bolt
- Insert bolt through bracket first
- Fold wings and push through hole
- Pull bolt toward you until wings seat
- Hold tension while tightening bolt
- Tighten until secure
Common toggle bolt mistakes:
- ❌ Wrong size hole (too small = can’t insert; too large = weak hold)
- ❌ Not maintaining tension during installation
- ❌ Overtightening (crushes drywall)
- ❌ Too few toggles (overloaded anchors)
Choosing Hardware by Wall Type
Drywall Over Wood Studs (Most Common)
Hardware choice: Lag bolts into studs
Why: Wood studs provide structural strength; lag bolts maximize that strength
Backup option: If studs don’t align with bracket, use lag bolts where possible + SnapToggles for remaining points
Metal Studs (High-Rise Condos)
Hardware choice: SnapToggles (preferred) or heavy-duty toggle wings
Why: Lag bolts don’t grip thin steel; toggles anchor behind both drywall and stud
Quantity: Use all available mounting holes; add extra anchors if possible
Drywall Only (No Studs Accessible)
Hardware choice: SnapToggles
Why: Best holding power for hollow wall mounting
Caution: Limit to lighter TVs (under 50 lbs); more toggles = better safety
Plaster and Lath
Hardware choice: Lag bolts into studs (if findable)
Why: Same as standard construction—you’re just going through thicker surface
Note: Use longer lag bolts to account for plaster thickness (3” minimum)
Concrete or Masonry
Hardware choice: Neither—use concrete anchors
Options: Tapcon screws, wedge anchors, sleeve anchors, or chemical anchors
Why: Lag bolts designed for wood; toggles designed for hollow walls; concrete needs its own hardware
Hollow Concrete Block
Hardware choice: Toggle bolts (into hollow cells) or concrete anchors (into solid sections)
Assess: Determine if you’re drilling into hollow cell or solid web
Hardware Capacity Calculations
Determining What You Need
Calculate total load:
- TV weight (check specifications)
-
- Mount weight (typically 5-15 lbs)
- = Total static load
Apply safety factor:
- Static loads: multiply by 1.5x
- Full-motion mounts: multiply by 2-3x (leverage increases load)
Example:
- 65” TV: 50 lbs
- Mount: 10 lbs
- Total: 60 lbs
- With 2x safety factor: 120 lbs required capacity
Matching Hardware to Load
If mounting to studs (lag bolts):
- Two 1/4” x 3” lag bolts = 500+ lbs capacity
- Exceeds requirement easily
If mounting to drywall (toggles):
- Four SnapToggles = 1,000+ lbs theoretical capacity
- Exceeds requirement with margin
When to add more anchors:
- Full-motion mount (extended position multiplies force)
- Large TV (85”+)
- Any uncertainty about wall condition
- Peace of mind
Special Hardware Situations
Hybrid Mounting (Studs + Drywall)
Scenario: Bracket holes don’t all align with studs
Solution:
- Lag bolts into available studs (primary support)
- Toggle bolts for remaining holes (secondary support)
- Studs carry majority of load
Key: At least two attachment points should be in studs
Heavy TV on Metal Studs
Scenario: 75”+ TV in high-rise condo with steel studs
Solution:
- Maximum number of SnapToggles
- Route through metal stud when possible (additional strength)
- Consider plywood backer for extreme weights
- Professional installation recommended
Retrofit/Replacement Mounting
Scenario: Mounting in location with previous anchor holes
Problem: Old holes weaken surrounding drywall
Solutions:
- Shift bracket to avoid old holes
- Patch old holes, let cure, drill fresh
- Use larger anchors that span past damaged area
- Install backer board
Hardware Shopping Guide
What to Buy for Standard Installation
For wood stud mounting:
- 1/4” x 3” lag bolts (quantity: match bracket holes, typically 4)
- Fender washers (same quantity)
- Wood drill bit for pilot holes (3/16” for 1/4” lags)
For metal stud/drywall mounting:
- 1/4” SnapToggles (quantity: all bracket holes + 2 extra)
- Appropriate drill bit (typically 1/2” for 1/4” SnapToggles)
Where to Buy
Hardware stores:
- Home Depot, Lowe’s: Good selection of both
- Ace Hardware: Often has harder-to-find toggle types
Online:
- Amazon: Bulk quantities at better prices
- Toggle bolt manufacturer sites: Full product lines
Quality matters:
- Avoid unbranded discount hardware
- Name brands (TOGGLER, Hillman, Everbilt) are tested and rated
- Check reviews for actual weight test results
Common Mistakes to Avoid
Mistake 1: Using Included Mount Hardware on Wrong Wall
Problem: Mount hardware is often generic and assumes wood studs
Reality: If you have metal studs, the lag bolts in the box won’t work
Solution: Identify your wall type first, then source appropriate hardware
Mistake 2: Plastic Drywall Anchors for TV Mounting
Problem: Plastic expansion anchors are for pictures, not TVs
Reality: Maximum capacity of 20-50 lbs is inadequate
Solution: Use proper toggle bolts, never plastic anchors
Mistake 3: Not Enough Anchors
Problem: Using minimum number of fasteners
Reality: More anchors = better load distribution and safety margin
Solution: Use every available mounting hole; add more if possible
Mistake 4: Wrong Size Hardware
Problem: Using smaller/lighter hardware than needed
Reality: Undersized hardware creates single point of failure
Solution: When in doubt, size up; there’s no penalty for oversized hardware
Mistake 5: Skipping Pilot Holes
Problem: Driving lag bolts without pilot holes
Reality: Splits wood and reduces holding power
Solution: Always drill appropriately sized pilot hole
Quick Reference: Hardware Selection
| Wall Type | Primary Hardware | Secondary Option |
|---|---|---|
| Drywall + wood studs | Lag bolts | SnapToggles (non-stud points) |
| Metal studs | SnapToggles | Heavy-duty toggle wings |
| Drywall only | SnapToggles | Spring toggle wings |
| Plaster + lath | Lag bolts (long) | SnapToggles (if no stud access) |
| Concrete | Concrete anchors | Chemical anchors |
| Brick | Masonry anchors | Tapcon screws |
When to Call a Professional
Hardware situations that benefit from expertise:
Uncertain wall type:
- Not sure what’s behind the wall
- Multiple wall types in mounting area
Heavy TV + challenging wall:
- 75”+ TV on metal studs
- Large full-motion mount
- No accessible studs
Previous failed installation:
- Damaged anchor points
- Unusual construction discovered
High-stakes installation:
- Very expensive TV
- Above high-traffic areas
- Commercial or rental properties
Professional Hardware Selection
At Express Mounting, we bring the right hardware for every situation:
✅ Wall type assessment before hardware selection
✅ Professional-grade fasteners exceeding minimum requirements
✅ Proper installation technique maximizing hardware strength
✅ Verification testing confirming secure attachment
✅ Insurance coverage backing our work
Why hardware matters:
The difference between a $2 plastic anchor and a $2 SnapToggle is nothing in cost—but everything in safety. Professional installation uses the right hardware, correctly installed, every time.
👉 Visit ExpressMounting.com to schedule your professional TV mounting with proper hardware included.
📍 Express Mounting — The right hardware, the right technique, the right results throughout Atlanta.
